Technical Information
Service Manual
12 15
14
34
5
6
7
8
913
11
12
10
No. Name
1 Neutral wire
2 Needle stand for indoor fan
3Auto button
4 Up&down swing motor
5 left&right swing motor
6Interface of temperature sensor
7
Terminal for display board
connection
8Terminal of jumper cap
9 Communication wire
10
Connect earthing wire(only fo
r
the mode with this function)
11 Fuse
12 Live wire interface
13
14
15
Detecting plate(WIFI )
Wired controller (only for th
e
mode with this function)
Interface of gate control (only
for the mode with this function)
5.2 PCB Printed Diagram
● Top view
Indoor Unit
● Bottom view
