Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model TW09HQ3D6D TW12HQ3D6D
Product Code CB460005700_L81560 CB460001400_L81560
Power Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 50/60 50/60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 9000 12000(2900~15354)
Heating Capacity Btu/h 9000 12200(3071~18766)
Cooling Power Input W 540 785(75~1500)
Heating Power Input W 610 940(250~1600)
Cooling Power Current A 3.05 3.9
Heating Power Current A 3.15 5.3
Rated Input W 1500 1600
Rated Current A 6.2 6.5
Air Flow Volume(SH/H/MH/M/ML/L/SL) CFM 424/383/353/324/294/265/206 850/800/750/600/550/450/400
Dehumidifying Volume Pint/h 1.69 2.96
EER (Btu/h)/W 16.67 15.3
COP (Btu/h)/W 14.75 12.98
SEER 30.5 30.5
HSPF 14 14
Application Area yd
2
19.1-28.7 19.14-28.70
Indoor Unit
Model of indoor unit TW09HQ3D6DI TW12HQ3D6DI
Indoor Unit Product Code CB460N05700_L81560 CB460N01400_L81560
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ4 1/6X27 4/5 Ф4 3/16X27 1/2
Fan Motor Cooling Speed (SH/H/MH/M/
ML/L/SL)
r/min 1250/1170/1100/1020/960/650/600
1400/1300/1200/1100/1000/900/800
/550
Fan Motor Heating Speed (SH/H/MH/M/
ML/L/SL)
r/min 1300/1200/1120/1040/960/880/800
1400/1270/1200/1130/1050/980/900
/-
Output of Fan Motor W 60 60
Fan Motor RLA A 0.09 0.09
Fan Motor Capacitor μF / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ 9/32 Ф1/4
Row-n Gap inch 2-1/16 2-1/16
Coil Length (LXDXW) inch 28 9/64X1X12 28 13/16X1X12
Swing Motor Model MP35CJ/MP24HF MP35CJ/MP24HF
Output of Swing Motor W 2.5/1.5 2.5/1.5
Fuse A 3.15 3.15
Sound Pressure Level (SH/H/MH/M/
ML/L/SL)
dB (A) 46/40/38/36/33/31/19 49/46/43/40/37/34/30
Sound Power Level (SH/H/MH/M/ML/L/
SL)
dB (A) 56/50/48/46/43/41/29 /
Dimension (WXHXD) inch 38 13/64X11 13/16X8 13/16 38 13/64X11 13/16X8 13/16
Dimension of Carton Box (LXWXH) inch 40 55/64X15X12 40 55/64X15X12
Dimension of Package (LXWXH) inch 41X15X12 39/64 41X15X12 39/64
Net Weight Ib 29.8 29.8
Gross Weight Ib 36.4 36.4
