Installation and Maintenance

Service Manual

Above data is subject to change without notice.

No.

Description

Part Code

QtyTW18HQ3D6DO TW24HQ3D6DO

Product Code CB437W01500_L81560 CB437W01700_L81560

1 Front Grill 016004060005 016004060005 1

2 Fan Motor 15010400000102 15010400000102 1

3 / / / /

4 Radiator 49015215 4901521501 1

5 Main Board 300027000040 300027000224 1

6 Electric Box Assy 100002000485 100002000598 1

7 Terminal Board Support sub-assy 01715016A 01715016 1

8 Terminal Board 42200006001401 42200006001401 1

9 Handle 26233053 26233053 1

10 Left Side Plate 01305043P 01305043P 1

11 Coping 01255020P 01255020P 1

12 Motor Support Assy 000046000019 017012000015 1

13 Condenser Support Plate 01175092 01175092 1

14 Clapboard Sub-Assy 01235091 017021000067 1

15 Condenser Assy 011002000242 011002000340 1

16 Rear Grill 01475013 01475013 1

17 Wiring Clamp 26115004 26115004 1

18 Temperature Sensor 3900030901 3900030901 1

19 Right Side Plate 0130504402P 0130504402P 1

20 Handle Assy 02113109 02113109 1

21 Cut off Valve 07130239 07130239 1

22 Valve Support Sub-Assy 0170506101P 0170506101P 1

23 Valve Support Block 26113017 26113017 1

24 Electronic Expansion Valve assy 030174060029 030174000045 1

25 4-Way Valve Assy 030152000081 030152000081 1

26 Compressor and Fittings 00105251 00105251 1

27 Drainage Connecter 06123401 06123401 1

28 Chassis Sub-assy 02803315P 017000000166P 1

29 Drainage hole Cap 06813401 06813401 1

30 Axial Flow Fan 10335013 10335013 1

31 Cabinet 0143500401P 0143500401P 1

32 Valve Cover 22245003 22245003 1
