Resistance Table of Tube Temperature Sensors for Indoor and Outdoor (20K)
Temp(
ć
) Resistance(kΩ) Temp(
ć
) Resistance(kΩ) Temp(
ć
)Resistance(kΩ)Temp(
ć
)Resistance(kΩ)
-19 181.4 20 25.01 59 5.13 98 1.427
-18 171.4 21 23.9 60 4.9489
91
.386
-17 162.1 22 22.85 61 4.773100 1.346
-16 153.3 23 21.85 62 4.605101 1.307
-15 145 24 20.9 63 4.443102 1.269
-14 137.2 25 20 64 4.289103 1.233
-13 129.9 26 19.14 65 4.14 1041.198
-12 123 27 18.13 66 3.998105 1.164
-11116.5 28 17.55 67 3.861106 1.131
-10 110.3 29 16.8 68 3.729107 1.099
-9 104.6 30 16.1 69 3.603108 1.069
-8 99.13 31 15.43 70 3.481109 1.039
-7 94 32 14.79 71 3.364110 1.01
-6 89.17 33 14.18 72 3.252111 0.983
-5 84.61 34 13.59 73 3.144112 0.956
-4 80.31 35 13.04 74 3.04 11
30
.93
-3 76.24 36 12.51 75 2.94 1140.904
-2 72.41 37 12 76 2.844115 0.88
-1 68.79 38 11.52 77 2.752116 0.856
0 65.37 39 11.06 78 2.663117 0.833
1 62.13 40 10.62 79 2.577118 0.811
2 59.08 41 10.2 80 2.495119 0.77
3 56.19 42 9.803 81 2.415120 0.769
4 53.46 43 9.42 82 2.339121 0.746
5 50.87 44 9.054 83 2.265122 0.729
6 48.42 45 8.705 84 2.194123 0.71
7 46.11 46 8.37 85 2.125124 0.692
8 43.92 47 8.051 86 2.059125 0.674
9 41.84 48 7.745 87 1.996126 0.658
10 39.87 49 7.453 88 1.934127 0.64
11 38.01 50 7.173 89 1.875128 0.623
12 36.24 51 6.905 90 1.818129 0.607
13 34.57 52 6.648 91 1.736130 0.592
14 32.98 53 6.403 92 1.71 1310.577
15 31.47 54 6.167 93 1.658132 0.563
16 30.04 55 5.942 94 1.609133 0.549
17 28.68 56 5.726 95 1.561134 0.535
18 27.39 57 5.519 96 1.515135 0.521
19 26.17 58 5.32 97 1.47 1360.509
