Installing the MP/8 V.34 2-7
45 to DB-9 adapters. Use these to plug the cable into the
terminals or network.
4. Plug the power cable into the power jack at the back of the
unit. Plug the cable into a standard 115-volt AC wall
socket.
5. Power on the unit. The Run/Fail LED should emit a green
light. If it does not indicate that the power is on, make sure
the power cable is attached tightly and the power switch is
on.
RJ11
cables
RJ45
cables
