2-4 MP/8 V.34: Getting Started
Figure 2-2. Mounting an MP/8 V.34 modem in a rack.
c Insert screws in the top left and top right slots and start
threading them.
d Beginning with the two bottom screws, tighten all four
until the unit is secure.
Setting the DIP Switches
The DIP switches, located on the rear panel between the RS-232
and Telco ports, are for adapting the modem to your equipment
and system requirements. Each set of DIP switches controls 8
modems.
Figure 2.3 shows the DIP switches in their factory default
settings, which reflect typical system requirements such as:
Auto Answer enabled, no result codes, no Data Terminal Ready
or Carrier Detect override. See Table 2.1 for switch options to
decide if the factory settings need to be changed.
