Configuring and Testing Using the Windows Utility 3-3
Table 3.1&F1 Hardware Flow Control Default Template
Options Setting Description
Handshake option B0 ITU-T answer sequence
Error control &M4 Normal/error control
Data compression &K1 Enabled
Transmit data hardware &H1 Hardware flow control
Rec'd data hardware flow control &R2 Enabled
Rec'd data software flow control &I0 Disabled
Serial port rate select &B1 Serial port rate fixed higher than
connect rate
Link rate select &N0 Variable
Result code subset X7 Extended—all codes
Protocol response codes &A3 Full protocol codes
Tone/Pulse dialing P Pulse dial
Online local echo F1 Disabled
Remote Digital Loopback (RDL) &T5 Deny RDL
Normal/Leased &L0 Normal phone line
Data Set Ready operations &S0 Override enabled
Break handling &Y1 Clear buffer, send immediately
Stored telephone number &Z0−9=0 Blank
Pulse dial make/break ratio &P0 U.S./Canada
Guard tone &G0 U.S./Canada
Word length* 8
Parity* 0 None
DTE rate* ( Kbps) 19.2 –
* Detected by the modem from the AT prefix of the &W com mand
that writes your defaults to NVRAM. Set your software to the desired
word length, parity, and serial port rate defaults before sending the
modem the AT . . . &W string.
