Operating as follows:
Acid density values(kg/at 20
)
1.28 battery charged
1.21 battery half charged
1.16 battery empty
Figure 7: pull the power plug out or the socket-outlet.
Figure 8: first disconnect the black charging lead from the
negative pole of the battery.
Figure 9: then disconnect the Ed charging lead from the
positive pole of the battery.
Figure 10: screw or press the battery plug back in place.
Overload protection
Figure 11: the flat fuse provides protection from polarity
reversal and short-circuiting. A defective fuse has to be
replaced by one of identical.
Please note: at automatic circuit-breaker interrupts the
charging in the event of thermal overloading. The
circuit-breaker switches on again automatically after a
cooling interval.
