EN60335-2-29 The standard of battery charger in Europe
Transformer in single phase—Rectifier
Please read the instruction manual
carefully before using
Using indoors only
IP20C Level of protection
The anode and cathode of battery
Specification
TBC1601
TBC1601-4
(IRAM plug)
EN60335-2-29
Voltage
220-240V~
50/60Hz
Voltage
12/24V
Current
0.9A
Current
9/4A
Fuse
20A
Fuse
2A
RATED INPUT RATED OUTPUT
1~ 1~
BATTERY MAX180Ah MIN28Ah
Disconnect the supply before making or breaking the connections to the battery.
WARNING: Explosive gases. Prevent flames and sparks. Provide adequate ventilation during charging.
I
BOOST
12A I
min
4A
IP20C
UTBC1601
Voltage
110-120V~
60Hz
Voltage
12/24V
Current
1.7A
Current
8/5A
Fuse
20A
Fuse
5A
RATED INPUT RATED OUTPUT
1~ 1~
BATTERY MAX150Ah MIN25Ah
Disconnect the supply before making or breaking the connections to the battery.
WARNING: Explosive gases. Prevent flames and sparks. Provide adequate ventilation during charging.
I
BOOST
12A I
min
8A
IP20C
TBC1601S
(SAA Plug)
TBC1601-9
TBC1601-8
TBC1601-6
