Set the RS-232 , at first set RS-232 working mode
(press TARE key to change, press ZERO key to enter)
P Prt: print weighing ticket when the PRINT/M+ key is
pressed,
P Cont: send weighing data continuously, connect to
PC ,
ASK: ask and answer mode (bi-direction mode), connect
to PC.
Command “R”: send weighing data to PC
Command “T”: do tare operate
Command “Z”: do zero operate
P cnt2: send weighing data continuously, connect to
PC, the other mode to send data.
P stab: print after stable.
P auto: auto print mode.
Seire: connect with remote display (also send
continuously)
Then set baud rate
After set working mode, display will show b xxx, this is
current baud rate, you select baud rate by TAKE key ad
press ZERO to enter.
If you set p cont, then need set communication
protocol, display will show Con x, con1 is standard
protocol, con2 and con3 is other communication
protocol, see detail in section 9.
If you set printer (P PRT, P AUTO), then you can set print
out format.
Display show “LAB x”, set gross/acc print format, you
can see detail below.
These parameter only available in MODE0 (normal
mode), see detail in section 12.
set printer type,
TY-TP: mini ticket printer
TY 711: A711 label printer
LP-50: LP-50 label printer
Then set ACC on/off.
Acc on: set accumulation and print working at the same
time.
Acc off: set print without accumulation.
