Totalcomp TRWS Series - Section 2 Specifications

TRWS indicator user’s manual
SECTION 2 SPECIFICATIONS
Model
TRWS
Resolution
Up to 30,000
Interface
RS-232 Output
Stabilisation Time
1 Seconds typical
Operating Temperature
0°C - 40°C / 32°F - 104°F
Power supply (external)
115 / 230 Vac, 120 / 240 Vac, 50/60Hz, 10 watts
Calibration
External
Display
6 digits 22mm LCD display, attached backlight
Indicator Housing
Stainless Steel
Zero range
0mV~5mV
Signal input range
0~15mV
ADC
Sigma delta
Internal counts
600,000
ADC update
Max 60 times /second
Load cell drive voltage
Max 5V/150mA
Load cells
Up to four 350 ohms cells
-2-
