TotalPond PF1200UV - ASSEMBLY INSTRUCTIONS - Replacing the bulb

6
12. Connect a length of tube from the outlet of a pump to the inlet of
the filter (upper hole). Connect a length of tubing from the
outlet of the filter (lower hole) to a water feature. Fig. 12
NOTE: Pump and tubing is NOT INCLUDED. The adapter
is compatible with 1 in. or 3/4 in. tubing.
Fig. 12
ASSEMBLY INSTRUCTIONS – Replacing the bulb
1. Disconnect the UV light from the outlet. Be sure to allow
sufficient time for the light to cool before disassembling the
light. Fig. 13
Fig. 13
2. Rotate the locking ring counterclockwise to remove the lamp
holder. Fig. 14
Fig. 14
GFCI
Locking
ring
Lamp
holder
Out
In
