SERVICING THE FLUSH TOWER
1. Turn off water supply and ush the toilet.
2. Remove the tank lid and place it upside down on a clean surface.
3. Note the orientation of the ush tower for reassembly.
4. Rotate the upper half of the ush tower so the arrow points towards
the overow tube and pull it up to remove it (ill. 1)
5. Remove the rubber seal gasket and rinse under running water to clean
(see Ill. 2).
6. Place the gasket back on the ush tower (Ill. 3).
7. Align arrow with the overow tube and install the ush tower back on
the base.
8. Rotate the ush tower to the same orientation (step 3).
9. Carefully, install the tank lid back on the tank.
10. Flush the toilet several times to verify proper operation. Check for
leakage.
ill.1 ill.2 ill.3
