ENGLISH

Screw

Washer

Nut

Wax seal

INSTALLATION PROCEDURE

1. Open the Unit Rough-In packaging.

Follow the Installation instruction to

complete the installation (ill. 1).

2. Place the template into position and

follow its instructions to prepare for

installing the toilet bowl.

Do not move the Unit Rough-

In on the Floor Flange after

wax seal is set. If this notice is

disregarded, discard the wax ring

and replace with new wax ring.

3. Place the toilet bowl over the Unit

Rough-In and the two mounting blocks,

by aligning the bowl outlet with the

Unit Rough-In opening (ill. 2).

4. Align the toilet perpendicular to the

back wall and parallel to side walls; it

should not sit crooked or diagonal (ill. 3).

Mounting block

Unit

Insert the toilet all the way

into position. If this notice is

disregarded, leakage may result.

NOTICE

ill.1

ill.2

ill.3
