6
SPECIFICATION
1．GAS CONCRETE NAILER
TYPE GSN40 GSN40A
Type of power Piston reciprocating
Applicable nails See 2. Available Nails.
Kinetic Energy 80(joule) 90(joule)
Nail Capacity 32 nails
（3- strip ） 42 nails （4- strip）
Ambient temperature -5 ℃～ 50℃(23℉to 120℉)
Dimensions 14.17 ＂
（L）×14.88＂（H）×4.37＂（W） 14.17＂（L）×15.12＂（H）×4.37＂
（W）
360mm （L）×378mm （H）×111mm （W）
360mm（L）×384mm （H）×111mm （W）
Weight 7.5lbs. （3.4kg Include battery ） 7.9lbs.(3.6kg Include battery ）
Cycle Rate 2 ～3 nails/second
Battery Pack NiMH 6V 1.5Ah
2
．Available Nails MIN MAX
Plastic strip nails
.250 ＂(6.3mm) .250 ＂(6.3mm)
.102 ＂(2.6mm) .120 ＂（3.05mm)
NOTE:
Choose the suitable nail length .
Choose overlong nail will cause the nail bending or the nail head emersion on the work piece.
Suggest to choose the suitable nail length according to the below table .
Work Conditions Nail Style Nail Length
wood
Nail through wood
2.6～3.05mm×30mm suitable length fire into concrete length
to concrete
2.6～3.05mm×35mm
2.6～3.05mm×40mm nail length
concrete
Nails through the wood into the concrete length is 15~20mm. e.g.:
wood thickness suitable length fire into the concrete length
10mm 30mm about 20mm
15mm 35mm about 20mm
20mm 40mm about 20mm
sheet steel
Nail through sheet
2.6～3.05mm×15mm
steel into concret e 2.6～3.05mm×19mm suitable length
2.6～3.05mm×22mm fire into concrete length
2.6～3.05mm×25mm
concret nail length
Nails through the sheet steel into the concrete length is 12~20mm.
(sheet steel thickness not greater than 3mm)
19/32＂(15mm)
1-9/16＂40mm
L
d
dXL
