Four-channel Amplifier
15
Four-channel Amplifier
The DA415 4-channel amplifier is shown in the figure below.
DA415 Four-channel Amplifier
Unlike the 3-channel model, the 4-channel amplifier does not support daisy-chaining of
components; the RJ45 connectors for Zones A and B are both inputs.
Amplifier Connectors
