Introduction
The DA415amplifier is available in two versions:
• A 3-channel version, installed in the Mini-Platinum speaker system.
• A 4-channel version, offered in the TouchTunes Ovation model wall-mounted jukebox.
Package Contents
The DA415 package contains the following components:
The following accessories for the DA415 amplifier are also available from TouchTunes:
Specifications
• Left channel / Right channel: 150W (RMS), 4 ohms per channel.
• Bridged bass channel: 300W (RMS), total load 8 ohms (3-channel amplifier only).
• Total harmonic distortion: 0.03%.
• Frequency response (all the channels): 20Hz- 20KHz, ± 0.5 dB.
• Stereo sound separation: ≥ 75 dB.
• Signal to noise ratio: ≥ 96 dB.
• Input ± 7V RMS balanced.
• Power: 90 to 130 V AC.
• Maximum power consumption: 1000W.
• Dimensions: Width=230mm, Height=85mm, Depth=330mm.
• Weight: 4.5 kg.
Part No. Description Quantity
700039-002 DA415 amplifier (3-channel) 1
OR
700039-001 DA415 amplifier (4-channel) 1
AND
300180-026 AC power cable 1
Part No. Description
300142-018 Category 5 cable, RJ45-RJ45
100000-001 Euroblock connector kit
