tousek ST 61 - Connections and Adjustments

tousek / EN_ST-61_07 / 25. 03. 2020 - 7 -
Main layer Sub layer Adjustments
buttons/switches

page 8, 9
G
impulse button
 OPEN/STOP/CLOSE
 OPEN/CLOSE/OPEN
 OPEN
 DEAD MAN
*) if impulse button is
set to DEADMAN, then
the pedestrian and
close button are also
set automatically to
DEADMAN mode.
(not selectable under
„pedest.- button“)
pedestrian button
 OPEN/STOP/CLOSE
 OPEN/CLOSE/OPEN
 OPEN
 Impulse OPEN
 DEAD MAN
*)
safety

page 10–13
G
inner photocell
 active
 not active
G
outer photocell
 active
 not active
G
main safety edge 1
 active
 not active
 radio edge TX310
G
main safety edge 2
 active
 not active
 radio edge TX310
photocell function inside
 during closing reverse
 stop - after release open
 during opening stop - then open
photocell function outside
 during closing reverse
 stop - after release open
PHC-pause time
 no inuence of photocell
 abort pause time
 re-start of pause time
 immediate close after opening
PHC-self test
 active
 not active
left leaf

page 16
G
motor (left)
 motor ON
 motor OFF
no left operator:
> Motor OFF !
G
delay left leaf
 opening delay
 closing delay
G
delay time left
 0...25s  = 2s
ARS response time
 0,15...0,95s [increment: 0,05]  = 0,50s
max. force
 20...100%  = 70%
soft stop time
 0...25s  = 5s
soft start
 not active  active
only with SWING X !
right leaf

page 16
G
motor (right)
 motor ON
 motor OFF
no right operator:
> Motor OFF !
G
delay right leaf
 opening delay
 closing delay
G
delay time right
 0...25s  = 2s
ARS response time
 0,15...0,95s [increment: 0,05 ]  = 0,50s
max. force
 20...100%  = 70%
soft stop time
 0...25s  = 5s
soft start
 not active  active
only with SWING X !
operating mode

page 16, 17
impulse logic
 stop, start of pause time
 impulse suppression when opening
 pause time extension
G
operating mode
 impulse mode
 automatic 1...255s [increment: 1]
partial opening
 25...100%  = 100%
automatic mode
 complete/partial opening
 only complete opening
 only partial opening
pause time logic
 no inuence
 permanent open in automatic mode
closing edges
 left/right
 inside/outside
limit tolerance
 3...20  = 20
lights/lamps

page 18
prewarning OPEN
 OFF, 1...30s  = OFF
prewarning CLOSE
 OFF, 1...30s  = OFF
courtyard lamp
1
 OFF, 5...950  = OFF
control lamp
1
 illuminates during open and close
 blinks slowly / illuminates / blinks
 illuminates in open position
peripherals

page 19–21
electric lock
 switched o󰀨
 1...10s
visible only
if activated under „locking“
reverse stroke
reverse stroke only with active locking!
 switched o󰀨
 0,5...8s
additional module
 courtyard/control lamp
 status display 1
 status display 2
locking
 e-lock/magnetic clamp
 motor lock
motor lock
 OPEN and CLOSE
 only OPEN
 only CLOSE
visible only
if activated under „locking“
diagnosis

page 22
status display
 status display
delete position
 NO
 YES
factory setting
 NO
 YES
software version
 show software version
serial number
 show serial number
1)
The menu points courtyard lamp and control lamp will only appear on display if in menu
„Additional module“  courtyard lamp/control lamp is selected.
Swing gate control unit ST61
+
–
Menu structure Adjustments - overview
ESC ENTER
Note: some adjustments regarding function or operating logic can only be executed if gate is closed and if the display shows „ready“.
