HGM410N/HGM420N GENSET
CONTROLLER USER MANUAL
11
93 Gen Over Volt Delay (0-20.0)s 10.0
When generate voltage exceeds shutdown value
and last for a whi-le, gen over volt shutdown is
acti-ve.
94 Gen Over Freq Delay (0-20.0)s 2.0
When generate frequence ex-ceeds shutdown
value and last for a while, gen over freq shutdown
is active.
95 Disconnect OP Delay (0-20.0)s 0.0s
When disconnect conditions include oil pressure
and engine oil pressu-re is higher than disconnect
oil pressure delay, the genset is re-garded as start
successfully and starter will dis-connect.
96 Timing Start (0-1) (0-1) 0 0 0: Disabled; 1:Enabled 0:No-load; 1:On-load
97
Timing Start Cir-cu-
late
(0-2) (
1-31)
(0-7)
(1-23)h
(1-59)min
(0-30000)min
0
1
0
0
0
30
0: monthly; 1: weekly; 2:daily
Day(0:monthly is active)
Week(0:weekly is active)
Prohibit start time (h)
Prohibit start time (min)
Duration
98 Auto Start Inhibi-ted (0-1) 0 0: Disabled; 1:Enabled
99
Auto Start Circula-te
Inhibited
(0-2)
(1-31)
(0-7)
(1-23)h
(1-59)min
(0-30000)min
0
1
0
0
0
30
0: monthly; 1: weekly; 2:daily
Day(0:monthly is active)
Week(0:weekly is active)
Prohibit start time (h)
Prohibit start time (min)
Duration
100 Over Power
(0-2)
(0-6000)kW
(0-6000)kW
(0-3600)s
0
304
290
5
0 Inactive; 1 Warn; 2 Alarm Shutdown
Over power setting value
Over power warn return
Over power delay
When power is higher than preset value and du-
ration exceeds than delay, over power warning is
active. Return and delay value can be set.
101 Date Set the date of controller.
102
Custom Sensor
Curve
(0-3) 0
0 Custom temperature sensor
1 Custom pressure sensor
2 Custom level sensor
3 Custom auxiliary sensor
Choose sensor which need to be set, input every
point(8 points need to be input) resistance and
corresponding value(or current, voltage) of curve.
Note1: Note1: The default value in “No.” column is for HGM420N and the number value needs to minus 5 for HGM410N.
Note2: Note2: If “high temperature inhibit” is congured, or set auxiliary input as “inhibit high temperature stop” and this input is active, when
temperature is higher than the preset value, or high temperature alarm input is active, controller will send warning signal only and not
stop the unit.
Note3: Note3: If “low oil pressure inhibit” is congured, or set auxiliary input as “inhibit low oil pressure stop” and this input is active, when
oil pressure is lower than the preset value, or low oil pressure alarm input is active, controller will send warning signal only and not stop
the unit.
Note4: Note4: If “low fuel level inhibit” is congured, or set auxiliary input as “inhibit low fuel level stop” and this input is active, when fuel
level is lower than the preset value, or low fuel level alarm input is active, controller will send warning signal only and not stop the unit.
Note5: Note5: Multiplex Input can be set as “auxiliary input” or “level sensor”; if one of them is set successfully, then the corresponding items
are active. For instance, if set “Multiplex Input 3” as “Auxiliary Input”, the related conguration items of auxiliary input 3 are active; if set
“Multiplex Input 3” as “Level Sensor”, the related conguration items of level sensor are active;
Note6: Note6: If default password (0318) isn’t changed, it doesn’t need to input when conguring parameters via PC software; if the password
is changed for the rst time via PC software, it need to input password in password window.
Note7: Note7: Between input correct password and LCD back light haven’t got dark, input parameter numbers can enter parameter setting
interface when enters “Password Input” again.
Note8: Note8: In teeth conguration interface, congure teeth status and power large than 20Hz, press start key for auto calculating teeth
numbers and press conrm key for changing teeth numbers.
