Toyama SmartGen HGM400N Series User Manual

HGM410N/HGM420N GENSET
CONTROLLER USER MANUAL
10
72
Pressure Sensor
Curve
(0-12) 8 SGX See 7.4
73 Multiplex Input 1 (0-1) 0
0: Digital Input 3
1: Level Sensor
74 Level Sensor Curve (0-7) 3 SGD See 7.4
75 Multiplex Input 2 (0-3) 0
0: Digital Input 4 1: Temperature Sensor 2: Oil
Pressure Sensor 3: Level Sensor Note 5
76 Cong. Sensor Curve (0-9) (0-9) (0-5) 8 8 3 SGX SGX SGD
77 Poles (2-64) 4
0:Dened temperature sensor
1: Dened pressure sensor
2: Dened liquid level sensor
Select the sensor, input corresponding 8 values.
78 Temp. Sensor Open (0-2) 1
0:Indication; 1:Warn; 2:Shutdown (temperature
sensor will show “+++”);
79 OP Sensor Open (0-2) 1
0: Indication (oil pressure sensor will show “+++”);
1:Warn; 2:Shutdown
80
Fuel Level Sen-sor
Open
(0-2) 1
0: Indication (fuel level sensor will show “+++”);
1:Warn; 2:Shutdown
81 Cong. Sensor Open (0-2) 1
0: Indication (LCD display will show “+++”);
1:Warn; 2:Shutdown
82 Cooling Blower On (0-140)ºC 60
It controls the cooling blower to open or close if
the output port is congured as Cooling Blower.
83 Cooling Blower O󰀨 (0-140)ºC 40
84 Low Fuel Level Warn (0-100)% 20
When the liquid level of the exter-nal sensor falls
below the set value, “Low Fuel Level” timer is
initiated. (this only concerns fuel level sensor and
does not concern low fuel level warning signal via
congurable input port)
85 Gen Over Volt Warn (30-620)V 253
When genset voltage is over the point, genera-tor
over voltage is active. When the point is 620V,
generator over voltage is disa-bled.
86 Gen Under Volt (30-620)V 193
When generator voltage is under the point, genera-
-tor under voltage is active. When the point is 30V,
generator under voltage is disabled.
87 Gen Over Freq Warn (0-75.0)Hz 55.0
When generator’s frequency is over the point,
genera-tor over frequen-cy is active.
88
Gen Under Freq
Warn
(0-75.0)Hz 42.0
When generator frequency is lo-wer than the point,
warn alarm signal will be sent.
89
Gen Over Current
Warn
(50-130)% 110
When load cur-rent is over the point, over current
is active. When this value is 0, warn alarm signal
won’t be sent.
90 High Temp. Warn (80-140)ºC 95
When the tempe-rature value of the external
tem-perature sensor exceeds the set value, “High
Temperature” timer is initiated. Detecting only after
safety on delay has expired. If the set value is 140,
high tempe-rature signal will not be sent (this only
concerns external tempera-ture sensor, not high
temperature signal via cong. input port).
91 Low OP Warn (0-400)kPa 124
When the exter-nal pressure sen-sor value falls
below this set value, “Low Oil Pressure” timer
is initiated. Detec-ting only after safety on delay
has expired. If the set value is 0, low oil pressure
signal will not be sent (this only con-cerns pressu-
re sensor and does not concern low oil pressure
war-ning signal via congurable input port)
92 Aux. Sensor Warn
(80-140)ºC (0-400)kPa
(0-100)%
95
Respective cor-responding with 90 temp. sensor,
91 pressure sen-sor and 84 level sensor in this
table.
