Toyama SmartGen HGM400N Series User Manual

HGM410N/HGM420N GENSET
CONTROLLER USER MANUAL
9
39 Over Current Delay (0-3600)s 30
When load current has exceeded the set value and
the “over current” delay has expired, over current
alarm is initiated. When the set value is 0, only
warning and not to shutdown the generator.
40 Fuel Pump On (0-100)% 25
When fuel level has fallen below the set value for
10s, “Fuel Pump On” alarm is initiated.
41 Fuel Pump O󰀨 (0-100)% 80
When fuel level has exceeded the set value for 10s,
“Fuel Pump O󰀨” alarm is initiated.
42 Aux. Output 1 (0-17) 14 Factory default: Fuel Relay Output
43 Aux. Output 2 (0-17) 2 Factory default: Energized To Stop
43 Aux. Output 3 (0-17) 5 Factory default: Gens closed
44 Aux. Output 3 (0-17) 3 Factory default: Idle Control
45 Aux. Output 4 (0-17) 5 Factory default: Close Generator
46 Aux. Output 5 (0-17) 6 Factory default: Mains Closed
47 Digital Input 1 (0-15) 1 Factory default: High Temperature Input
48 Digital Input 1 Active (0-1) 0 Factory default: Close to active
49 Digital Input 1 Delay (0-20.0)s 2.0
50 Digital Input 2 (0-15) 2 Factory default: Low Oil Pressure Warning Input
51 Digital Input 2 Active (0-1) 0 Factory default: Close to active
52 Digital Input 2 Delay (0-20.0)s 2.0 Factory default: close
53 Digital Input 3 (0-15) 10 Factory default: Remote Start
54 Digital Input 3 Active (0-1) 0 Factory default: Close to active
55 Digital Input 3 Delay (0-20.0)s 2.0 Factory default: close
56 Digital Input 4 (0-15) 11 Factory default: Fuel Level Warn
57 Digital Input 4 Active (0-1) 0 Factory default: Close to active
58 Digital Input 4 Delay (0-20.0)s 2.0 Factory default: close
59 Power On Mode (0-2) 0 0: Stop Mode 1: Manual Mode 2: Auto Mode
60 Module Address (1-254) 1 Communication address of controller.
61 Passwords (0-9999) 0318
62 Crank Disconnect (0-6) 2
There are 3 conditions of disconnecting starter
with engine: Generator Frequency, Magnetic
Pickup, Oil Pressure. Each condition can be used
alone and simultaneously to separating the start
motor and genset as soon as possible. See 7.5
63
Disconnect Magnetic
Pickup
(0-3000)r/min 360
When engine speed higher than the set value, star-
ter will be disconnected.
63
Disconnect Magnetic
Pickup
(0-3000)r/min 360
When engine speed higher than the set value, star-
ter will be disconnected.
64 Disconnect Gen Freq (10.0-30.0)Hz 14.0
When generator frequency higher than the set
va-lue, starter will be disconnected.
65 Disconnect OP (0-400)kPa 200
When generator oil pressure higher than the set
value, starter will be disconnected.
66
High Temp. Inhibit
Enabled
(0-1) 0
Factory default: when high temperature occurs,
shutdown alarm is initiated. Note 2
67
Low OP Inhibit Ena-
-bled
(0-1) 0
Factory default: when low oil pressure occurs,
shu-tdown alarm is initiated. Note 3
68
Low Fuel Level
Inhibit
(0-1) 1
Factory default: when low fuel level occurs, shu-t-
down alarm is initiated. Note 4
69
Cong. Sensor
Inhibit
(0-1) 1
Factory default: when cong. sensor value higher/
lower than the set value (particular case depends
on the sensor type), shutdown alarm is initiated.
70 AC System (0-3) 0 0: 3P4W; 1: 2P3W 2: 1P2W; 3: 3P3W
71 Temp. Sensor Curve (0-12) 8 SGX See 7.4
