--LUBRICATION OIL COOLER
RE M O VAL
1 . DRAI N E NG I NE CO O L ANT
2. REMOVE TIMING BELT (See page EM -- 13)
3. REMOVE INJECTION PIPES (See pa ge FU -- 5)
4. REMOVE INJECTION PUMP (See pa ge FU -- 18)
5. REMOVE OIL DIPSTICK AND GUIDE
(a) Remove the nut and oil dipstick guide assembly.
(b) remove the O--ring from the oil dipstick guide.
6 . RE MO V E O I L FI LT E R (S e e pa ge LU -- 2 )
7. REMOVE OIL COOLER AND OIL COOLER COVER AS -
SEMBLY
(a) Remove the 2 nuts and disconnect the vacuum pipe.
(b) Remove the 13 bolts, oil cooler, oil cooler cover assembly
and gasket.
8 . RE MO V E O I L P RE S S URE S E NDE R G AUG E
Remove the oil pressure sender gauge from the oil cooler cov-
er.
9. SEPARATE OIL COOLER AND OIL COOLER COVER
Remove the 4 nuts, oil cooler and 2 gaskets from the oil cooler
cover.
