640

9-1. Specifications

HIGHLANDER_U (OM48F09U)

■

Engine number

The engine number is stamped on the engine block as shown.

 2.7 L 4-cylinder (1AR-FE)

engine

 3.5 L V6 (2GR-FE) engine
