en-6
Parking brake warning lamp
When the parking brake is engaged, the warn-
ing lamp will light up to notify the operator.
The warning lamp will light up when the park-
ing brake is engaged. After disengaging the
brake to operate the vehicle, check to make sure
the warning lamp has turned off.
If the lamp does not go off even when the
parking brake switch is turned into the ON
position, contact your Toyota dealer to
request an inspection.
Sedimenter warning lamp
The sedimenter is a device for separating water
from the fuel.
1. The warning lamp comes on to indicate
water in the sedimenter exceeds the prede-
termined level while the engine is running.
2. If normal, the lamp comes on when the
ignition switch is turned to ON and goes
off when the engine starts.
3. If the lamp comes on while the engine is
running, drain water immediately. (See the
self service section for the draining
instructions.)
Continued operation with the lamp on may
cause seizure of the injection pump and
pump damage. If the warning lamp lights up,
always make sure to drain the water.
Fuel gauge
Indicates the amount of remaining fuel in the
fuel tank in terms of a 10-stage gradation scale.
The operator will be notified that remaining
fuel level is low when the two stages at far left
start blinking.
It takes some time for the indication to be stabi-
lized after refuelling and the ignition switch is
turned to ON.
• If the operating area is not level, attention
must be paid because the correct level may
not be indicated.
• When the gauge begins blinking, refuel as
soon as possible.
• In case of diesel engine, be sure to refuel it
before it runs out because when this occurs
it becomes necessary to bleed air from the
fuel supply system.
Glow indicator lamp
(3TNV88, 1DZ-II engine models)
Indicates heating of glow plugs.
When the ignition switch is turned to GLOW,
the lamp comes on and glow plug heating
begins. The lamp goes off automatically when
glow plug heating is complete. The engine will
start easily once the glow plugs are heated.
The glow indicator lamp is on for 2 seconds
when the engine coolant temperature exceeds
50ºC.
