Toyota 8FGU20 User Manual

SECTION INDEX
NAME
SECTION
GENERAL
0
ENGINE - CHASSIS
1
4Y-E REPAIR
1.1
1DZ-II REPAIR
1.2
4Y-E LPG DEVICE REPAIR
1.3
TRANSMISSION (Pn1•2•3 / Cu2•3)
2
TRANSMISSION (Cu1 Ton Series)
2.1
PROPELLER SHAFT
3
DIFFERENTIAL
4
FRONT AXLE
5
REAR AXLE
6
STEERING
7
BRAKE
8
BODY
9
MATERIAL HANDLING SYSTEM
10
MAST
11
CYLINDER
12
OIL PUMP
13
OIL CONTROL VALVE
14
MINI LEVER - JOYSTICK
15
SAS / OPS
16
SSTLIST - SERVICE STANDARDS LIST
17
MULTIFUNCTION DISPLAY DX (OPTIONAL)
18
ELECTRICAL SYSTEM TROUBLESHOOTING [except Cu1]
19
ELECTRICAL SYSTEM TROUBLESHOOTING [Cu1 ton series]
19.1
WIRING DIAGRAM
E
SERVICE INFORMATION BULLETINS SIB

Toyota 8FGU20 Specifications

General

Model	8FGU20
Category	Forklifts
Transmission	Automatic
Power Source	Internal Combustion Engine
Tire Type	Pneumatic
Load Capacity	4, 000 lbs
Fuel Type	LPG or Gasoline
Engine Type	Internal Combustion
Engine	Toyota 4Y Engine
Weight	3200 kg
Load Center	24 inches
Travel Speed (loaded/unloaded)	11.2 mph (18.0 km/h) / 11.8 mph (19.0 km/h)
Lift Speed (loaded/unloaded)	0.5 m/s (loaded), 0.6 m/s (unloaded)
Lowering Speed (loaded/unloaded)	0.5 m/s (loaded), 0.6 m/s (unloaded)
Turning Radius	2300 mm
Mast Height (lowered)	2100 mm
Wheelbase	59 inches
