Toyota Corolla - Page 87

87
2. Instrument cluster
Corolla_TMMT_EE (OM12F04E)
2
Instrument cluster
*
1
: These lights turn on when the engine switch is turned to the “ON” position
(vehicles without a smart entry & start system) or the engine switch is
turned to IGNITION ON mode (vehicles with a smart entry & start system)
to indicate that a system check is being performed. They will turn off after
the engine is on, or after a few seconds. There may be a malfunction in a
system if the lights do not come on, or turn off. Have the vehicle inspected
by any authorized Toyota dealer or repairer, or another duly qualified and
equipped professional.
*
2
: If equipped
*
3
: The light flashes in yellow to indicate a malfunction. The light flashes
quickly in green to indicate that the steering lock has not been released.
*
4
: The light comes on in yellow to indicate a malfunction.
*
2
Low windshield washer
fluid warning light
(P. 496)
*
1, 2
DPF system warning
light (P. 497)
*
1, 2
Tire pressure warning
light (P. 499)
*
2
(Yellow)
Speed limiter indicator
(P. 495)
