89
2. Instrument cluster
Corolla_TMMT_EE (OM12F04E)
2
Instrument cluster
*
1
: These lights turn on when the engine switch is turned to the “ON” position
(vehicles without a smart entry & start system) or the engine switch is
turned to IGNITION ON mode (vehicles with a smart entry & start system)
to indicate that a system check is being performed. They will turn off after
the engine is on, or after a few seconds. There may be a malfunction in a
system if the lights do not come on, or turn off. Have the vehicle inspected
by any authorized Toyota dealer or repairer, or another duly qualified and
equipped professional.
*
2
: If equipped
*
3
: The light flashes to indicate that the system is operating.
*
4
: The light does not turn on when the system is disabled.
CAUTION
 If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning lights not
come on when you start the engine, this could mean that these systems are
not available to help protect you in an accident, which could result in death
or serious injury. Have the vehicle inspected by any authorized Toyota
dealer or repairer, or another duly qualified and equipped professional
immediately if this occurs.
