LED status
The Alarm LED indicates the Alarm status:
Conditi
on
Alarm status light (LED)
Disarm state
LED off
Pre
-
arm
ing
state
LED on
Armed
state
LED blinking (slow)
Alarm
state
LED blinking (fast)
If the alarm was triggered during your absence, the blinkers will
blink 4 times and the buzzer 4 times when the doors are unlocked.
The alarm system memory will display via the LED what triggered
the alarm. The LED will display this until the vehicle is switched on.
Trigger
Alarm status light (LED)
Driver door
1
blink
I
ntrusion sensor
2 blinks
Bonnet
3 blinks
Trunk
5
blinks
Other door
6 blinks
Vehicle security system
7 blinks
Wiring attack
8 blinks
Unauthorized unlock
9 blinks
Level Monitor
10 blinks
Garage mode
The alarm system can be deactivated for a limited period of time.
During garage mode, all the alarm system functions are disabled.
To activate garage mode:
1. Make sure that the alarm is disarmed and the bonnet is
closed.
2. Switch on the vehicle (Ignition On).
3. Open the driver door.
4. Insert PIN Code
The hazards lights will give 5 flashes for confirmation.
After 10 cycles of Ignition on/off, the garage mode will be cancelled.
The hazards will flash 5 times. Garage mode can also be cancelled
by repeating the activation procedure.
Emergency Override
This procedure allows you to manually arm or disarm the alarm.
To disarm the system:
1. Press the button under the LED the number of times that
corresponds to the first digit of the PIN Code, with a
maximum 1.5s delay between one press and the next.
2. Wait for the LED to flash, then enter next digit.
3. Repeat the process for all four digits.
4. When the correct code is entered, the alarm will disarm.
To arm the system:
Use same procedure as above to arm the system. Alarm will arm
after second digit.
Troubleshooting
Issue
Cause
Buzzer bips 3x when vehicle is
locked
Bonnet is opened
Buzzer bips 4x when vehicle is
unlocked
Intrusion was detected in your absence,
please refer to chapter “LED status”
Long buzz
when vehicle is
locked
One of the doors is
opened
Blinkers blink every 12s
Starting Garage mode failed, close bonnet
and restart garage mode procedure.
Blinkers blink 5 times when
engine starts
Garage mode has just been cancelled
.
See
chapter “garage mode”
Warranty information
- In case of loss caused by fire, action of a third party, or
other accidents, or the user’s deliberate or accidental
misuse, incorrect use, or use under abnormal conditions,
repair of the product will be charged to the user.
- Toyota Motor Europe NV/SA is not liable for any incidental
loss caused by the use or non-use of this product.
- Toyota Motor Europe NV/SA is not liable for any damages
or incidents consequent to intentional misuse, accidental
misuse, or third party use of the device.
- The alarm system will not prevent the car from being
stolen.
-
Vehicle Security System
VSS4
Owner Manual – English
AOM 001 67
