CR2 AC750 Wireless Dual-Band Router
5
Chapter 2 Hardware Installation
2.1 Led indicators
The top panel contains LED indicators that show the status of the unit.
Name Status Indication
Power
Off Power is off.
On Power is on.
SYS/WPS
Flashing the LED flashes about two minutes during WPS working.
WAN
LAN(1-4)
Off There is no device linked to the corresponding port.
On
There is a device linked to the corresponding port but
there is no activity.
Flashing There is an active device linked to the corresponding port.
5GHz
Off The wireless function is disabled.
Flashing
The wireless function is enabled. The router is working on
5GHz radio band.
2.4GHz
Off The wireless function is disabled.
Flashing
The wireless function is enabled. The router is working on
2.4GHz radio band.
2.2 Back Rear Panel
The following parts are located on the rear panel.
