Chapter 2
Connect the Hardware
2. 1. Position Your Router
• The product should not be located in a place where it will be exposed to moisture or
excessive heat.
• Place the router in a location where it can be connected to multiple devices as well as
to a power source.
• Make sure the cables and power cord are safely placed out of the way so they do not
create a tripping hazard.
• The router can be placed on a shelf or desktop.
• Keep the router away from devices with strong electromagnetic reference, such as
Bluetooth devices, cordless phones and microwaves.
2. 2. Connect Your Router
Follow the steps below to connect your router.
If your internet comes from an Ethernet outlet, connect the router’s Internet port to it,
and then follow Step 4 and Step 5 to complete the hardware connection.
4
Modem
Power adapter
Power adapter
Router
1
2
3
Internet
1. Unplug your modem, and remove the backup battery if it has one.
2. Connect the power-off modem to your router’s Internet port with an Ethernet cable.
3. Power on the modem, and then wait about 2 minutes for it to restart.
4. Connect the power adapter to the router and turn on the router.
