39
Chapter 8
USB Settings
Windows
computer
Method 2:
Open the Windows Explorer (or go to Computer) and type the server
address \\tplinkwifi.net or ftp://tplinkwifi.net in the address bar, then
press Enter.
Mac
1 ) Select Go > Connect to Server.
2 ) Type the server address smb://tplinkwifi.net.
3 ) Click Connect.
4 ) When prompted, select the Guest radio box. (If you have set up a
username and a password to deny anonymous access to the USB
disks, you should select the Registered User radio box. To learn how
to set up an account for the access, refer to To Set Up Authentication
for Data Security.)
Tablet
Use a third-party app for network files management.
Tips:
You can also access your USB storage device by using your Network/Media Server Name as the server address. Refer
to To Customize the Address of the USB Storage Device to learn more.
8. 1. 2. Access the USB Device Remotely
You can access your USB disk outside the local area network. For example, you can:

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TP-Link Archer AXE75 and is the answer not in the manual?

TP-Link Archer AXE75 Specifications

General IconGeneral
Ethernet WANYes
SIM card slotNo
WAN connection typeRJ-45
3G/4G USB modem compatibility-
VPN serverOpenVPN Server
VPN supportOpenVPN Server PPTP VPN Server L2TP VPN Server
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11n
Ethernet LAN data rates2500 Mbit/s
Ethernet interface type2.5 Gigabit Ethernet
Ethernet LAN interface typeGigabit Ethernet
Number of guest networks (2.4 GHz)1
Ethernet LAN (RJ-45) ports5
IPv4 & IPv6 featuresDual stack IPv4/IPv6
Supported network protocolsIPv4, IPv6
Firewall securitySPI Firewall
Input current2.5 A
Output voltage12 V
Power source typeDC
Product typeTabletop router
Product colorBlack
LED indicatorsPower, WAN, WLAN
Transmit powerFCC: ≤29dBm (2.4 GHz), ≤28dBm (5 GHz), ≤22dBm (6 GHz) CE: ≤17dBm (2.4 GHz), ≤27dBm (5 GHz), ≤20dBm (6 GHz) dBmW
Antennas quantity6
Wi-Fi bandTri-band (2.4 GHz / 5 GHz / 6 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standardWi-Fi 6E (802.11ax)
WLAN data transfer rate (max)5400 Mbit/s
WLAN data transfer rate (first band)574 Mbit/s
WLAN data transfer rate (second band)2402 Mbit/s
Processor cores4
Processor frequency1700 MHz
Cables includedLAN (RJ-45)
Package depth265 mm
Package width328 mm
Package height120 mm
Package weight1530 g
Number of products included1 pc(s)
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90 %
Harmonized System (HS) code85176990
Sustainability certificatesFederal Communications Commission (FCC), RoHS
Weight and Dimensions IconWeight and Dimensions
Depth147.2 mm
Width272.5 mm
Height49.2 mm
