Chapter 1
Get to Know About Your Router
1. 2. 2. Back Panel
The following parts are located on the back panel.
Item Description
Power On/Off Button Press this button to power on or off the router.
Power Port For connecting the router to a power socket via the provided power adapter.
USB 3.0 Port For connecting your USB storage devices to the router.
2.5Gbps Internet Port For connecting to your modem or the Ethernet outlet.
2.5Gbps LAN Port (1) For connecting your PC or other wired devices to the router.
1Gbps LAN Port (2-4) For connecting your PC or other wired devices to the router.
Reset Button
Press and hold the button until the LED blinks to reset the router to its factory
default settings.
