User Manual
Code: ARCHER-C6U
ROUTER ARCHER-C6U 2.4 GHz, 5 GHz 300 Mbps + 867 Mbps TP-LINK
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2021-06-07 ARCHER-C6U 3/5
DHCP server:
Firmware update:
Protections:
WEP 64/128-bit, WPA/WPA2, WPA-PSK/WPA2-PSK
DoS attacks protection, SPI network firewall, domain filtering, IP and MAC filtering,
IP and MAC binding
Management interface: Web browser, TP-LINK Tether
Transmitter power:
max. 20 dBm @ 2.4 GHz
max. 23 dBm @ 5 GHz
Power supply: 12 V DC / 1.5 A (power adapter included)
Main features:
• MU-MIMO - a multi-antenna transmission function that allows to increase the
bandwidth and reliability of connection with the client of the network
• Beamforming (TxBF) - technology that allows to create a beam of radio waves in
order to improve the quality of connection with client devices located further away
from the signal source
• Airtime Fairness - technology that improves network performance when multiple
clients with different data rates appear in it
• Firewall
• Internet access filtering
• Static / dynamic routing
• Built-in 4-port switch
• Access Point
• The WPS function allows to easy establish an encrypted connection
• QoS
• Access control
• Remote management
• DMZ
• UPnP
• Port forwarding
• parental control
• Guest Network - a separate and secure network for guests
• DHCP client list
• VPN networks: Open VPN, PPTP VPN
• SSID hiding
• IPv6 compliance
• Smooth transmission in HD quality - IGMP Proxy/Snooping, Bridge VLAN, Tag
VLAN functions contribute to optimal IPTV transmission
• The USB 2.0 built-in storage port supports drive, media server, FTP server and
print server sharing functions
Operation temp: 0 °C ... 40 °C
Permissible relative humidity: 10 % ... 90 % (non-condensing)
Weight: 0.33 kg
Dimensions: 215 x 125 x 30 mm
Manufacturer / Brand: TP-LINK
Guarantee:
3 years
