TP-Link AX11000 User Manual

Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPA3 encryptions
Specifications
Software
Quality of Service: Device and Application Prioritisatio
WAN Type: Dynamic IP/Static IP/PPPoE/L2TP/PPTP
Management: Access Control, Local Management, Remote Management
DHCP: Server, DHCP Client List, Address Reservation
NAT Forwarding: Port Forwarding, Port Triggering, UPnP, DMZ
Dynamic DNS: DynDns, NO-IP, TP-Link
VPN Server: OpenVPN, PPTP VPN
Access Control: Local Management Control, Host List, White List, Black List
Firewall Security: SPI Firewall, IP and MAC Address Binding
Protocols: IPv4, IPv6
USB Sharing: Supports Samba(Storage)/FTP Server/Media Server
Guest Network: 2.4GHz Guest Network, 5GHz Guest Network
HomeCare™: Parental Controls, QoS, Antivirus
Others
Certification:
CE, FCC, RoHS
System Requirements:
Microsoft Windows 98SE/NT/2000/XP/VistaTM/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Cable or DSL Modem
Subscription with an internet service provider (for internet access)
Environment:
Operating Temperature: 0°C~40 (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F ~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Package Contents
Wireless Router Archer AX11000
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
For more information, please visit https://www.tp-link.com/products/details/cat-9_Archer-AX11000.html
or scan the QR code left
Specifications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co.,
Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright
©2019 TP-Link Technologies Co., Ltd. All rights reserved.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Attention: This device may only be used indoors in all EU member states and EFTA countries.
*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual

TP-Link AX11000 Specifications

General

Flash memory	512 MB
Certification	FCC, CE, RoHS
Internal memory	1024 MB
Processor cores	4
Built-in processor	Yes
Processor frequency	1800 MHz
DSL WAN	No
WAN connection type	RJ-45
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11ad, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	4804 Mbit/s
WLAN data transfer rate (third band)	1148 Mbit/s
Product type	Tabletop router
Product color	Black
VPN support	PPTP, OpenVPN
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	5 GHz_1: 11a 6Mbps：-96dBm, 11a 54Mbps:-78dBm 11ac VHT20_MCS0:-95dBm, 11ac VHT20_MCS11:-65dBm 11ac VHT40_MCS0:-93dBm, 11ac VHT40_MCS11:-62dBm 11ac VHT80_MCS0:-90dBm, 11ac VHT80_MCS11:-59dBm 11ac VHT160_MCS0:-87dBm, 11ac VHT160_MCS11:-54dBm 11ax HE20_MCS0:-94dBm, 11ax HE20_MCS11:-62Bm 11ax HE40_MCS0:-91dBm, 11ax HE40_MCS11:-59dBm 11ax HE80_MCS0:-88dBm, 11ax HE80_MCS11:-57dBm 11ax HE160_MCS0:-84dBm, 11ax HE160_MCS11:-54dBm 5 GHz_2: 11a 6Mbps：-96dBm, 11a 54Mbps:-78dBm 11ac VHT20_MCS0:-95dBm, 11ac VHT20_MCS11:-65dBm 11ac VHT40_MCS0:-93dBm, 11ac VHT40_MCS11:-62dBm 11ac VHT80_MCS0:-90dBm, 11ac VHT80_MCS11:-59dBm 11ac VHT160_MCS0:-87dBm, 11ac VHT160_MCS11:-54dBm 11ax HE20_MCS0:-94dBm, 11ax HE20_MCS11:-62Bm 11ax HE40_MCS0:-91dBm, 11ax HE40_MCS11:-59dBm 11ax HE80_MCS0:-88dBm, 11ax HE80_MCS11:-57dBm 11ax HE160_MCS0:-84dBm, 11ax HE160_MCS11:-54dBm 2.4 GHz： 11g 6Mbps：-97dBm, 11a 54Mbps:-79dBm 11n HT20_MCS0:-97dBm, 11n HT20_MCS7:-78dBm 11n HT40_MCS0:-95dBm, 11n HT40_MCS7:-75dBm 11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-67dBm 11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-64dBm 11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-64dBm 11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-61dBm
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Number of guest networks (2.4 GHz)	1
Transmit power	CE: \u003C20dBm(2.4GHz), \u003C23dBm(5.15GHz~5.35GHz); \u003C30dBm(5.47GHz~5.725GHz); FCC: \u003C30dBm(2.4GHz & 5.15GHz~5.25GHz & 5.725GHz~5.825GHz), \u003C24dBm(5.25GHz-5.35GHz & 5.47GHz-5.725 GHz) dBmW
Antennas quantity	8
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Supported network protocols	IPv4, IPv6
Package depth	290 mm
Package width	365 mm
Package height	120 mm
Package weight	2590 g
Number of products included	1 pc(s)
Cables included	LAN (RJ-45)
Browser supported	Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Output current	5 A
Output voltage	12 V
Power source type	DC

Weight and Dimensions

Width	288 mm
Height	184 mm
