TP-Link eap220 User Manual

2
English
2
Use an M3×6 pan-head screw to secure the T-rail
Clip onto the ceiling rail.
3
Attach the mounting bracket to the Ceiling T-rail
Clip using four M3x6 pan-head screws.
4
Attach the EAP to the mounting bracket by
aligning ARROW 1 (on the EAP) with ARROW 2
(on the mounting bracket), then rotate the EAP
clockwise until it locks into place.
5
Connect the Ethernet cable to the ETHERNET
port.

TP-Link eap220 Specifications

General

Brand	TP-Link
Model	eap220
Category	Network Router
Language	English
