1.3 Panel Layout
1.3.1 Top Panel
The music receiver’s LED is located on the top panel.
Name Status Indication
Status LED
On
White: The music receiver is powered on and ready to be paired.
Blue: A smart device is connected.
Off
The music receiver is powered off.
1.3.2 Back Panel
The music receiver’s ports are located on the back panel.
Item Description
Used to connect the music receiver to a power socket via the provided power cable.
Used to connect the music receiver to your music system via a provided audio cable.
Chapter 1 Introduction 2
