TP-Link M7000 Quick Installation Guide

FAQ (Frequently Asked Questions)
· Keep the device away from water, re, humidity or hot environments.
· Do not attempt to disassemble, repair, or modify the device. If you need service,
please contact us.
· Do not use the device where wireless devices are not allowed.
· Do not disassemble, crush, puncture, short external contacts, or dispose of the
battery in re or water.
· Do not leave a battery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of ammable liquid or
gas. Do not leave a battery subjected to extremely low air pressure that may
result in an explosion or the leakage of ammable liquid or gas.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE.
Please read and follow the above safety information when operating the device.
We cannot guarantee that no accidents or damage will occur due to improper
use of the device. Please use this product with care and operate at your own risk.
Safety Information
Charging Your Mobile Wi-Fi
!
· The Battery LED will be solid green when the Mobile Wi-Fi is fully charged.
·
The power adapter is not provided by TP-Link.
5V/1A
Method 1
Via a Wall Outlet (Recommended)
Method 2
Via a Computer
Managing Your Mobile Wi-Fi
tpMiFi App
1. Get the tpMiFi app from App Store or Google Play, or by
scanning the QR code.
2. Connect your wireless device to the Mobile Wi-Fi.
3. Launch tpMiFi and enter admin to log in.
Web Management Page
1. Connect your wireless device to the Mobile Wi-Fi. If it is a computer,
make sure it is set to obtain an IP address automatically.
2. Launch a web browser and visit http://tplinkmi.net or
http://192.168.0.1. Enter admin to log in.
For technical support, user manuals and more information,
please visit https://www.tp-link.com/support, or simply
scan the QR code.
Manage your Mobile Wi-Fi using any of the methods below. You can customize Wi-Fi settings, block Wi-Fi devices and more.
· Check the Data Roaming settings
If your SIM card is operated in a roaming service area, go to Dial-up, enable
Data Roaming and tap Done.
·
Check Mobile Data
Go to Dial-up to verify that Mobile Data is On. If not, enable it and tap Done.
·
Check Data Limit
Go to Device > Data Usage Settings to check whether your data usage has
exceeded the Total/Monthly allowance.
Q2. How do I restore the Mobile Wi-Fi to its factory default settings?
A. With the Mobile Wi-Fi powered on, remove the cover, then use a pin to
press and hold the Reset button until all LEDs turn on momentarily.
Note: Restoring the device to its factory defaults will clear all your settings.
Q1. What should I do if I cannot access the internet (the Internet
LED doesn’t light up)?
A. Visit the web management page (http://tplinkmi.net) on your phone,
enter admin to log in, then check the following:
·
Check PIN status
If the current SIM card status is PIN Locked, your SIM card is PIN
protected and you need to unlock it using the PIN code provided by your
mobile carrier.
·
Verify the mobile carrier parameters
1. Go to Dial-up, tap View prole details, and verify that the parameters
(i.e. APN, username and password) provided by your mobile carrier are
correct.
2. If the parameters are not correct, return to the Dial-up page and
create a new prole with the correct information.

TP-Link M7000 Specifications

General

Ethernet WAN	No
SIM card slot	Yes
3G/4G USB modem compatibility	-
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Device type	Cellular network router
Product type	Portable router
Product color	Black
LED indicators	Power, WLAN
Transmit power	20 dBmW
Output current	1 A
Output voltage	5 V
Battery capacity	2000 mAh
Power source type	Battery
Battery life (max)	8 h
USB port type	Micro-USB
Ethernet LAN (RJ-45) ports	0
4G standard	LTE-FDD
3G standards	HSPA, HSPA+, UMTS
Data network	3G, 4G, LTE
SIM card type	MicroSIM
4G bands supported	800, 850, 900, 1800, 2100, 2600 MHz
UMTS bands supported	850, 900, 2100 MHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	11b 11Mbps: -87.5dBm 11g 54Mbps: -74dBm 11n HT20 MCS7: -70dBm 11n HT40 MCS7: -68dBm
Ethernet LAN interface type	Not available
Security algorithms	SSID, WPA-PSK, WPA2-PSK
Certification	CE, RoHS
Mobile operating systems supported	Android, Windows Phone, iOS
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP
Package depth	95 mm
Package width	135 mm
Package height	50 mm
Package weight	150 g
Number of products included	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	56.6 mm
Width	94 mm
Height	19.7 mm
