NC230 HD Day/Night Wi-Fi Cloud Camera
HD Day/Night Cloud Camera, 300Mbps Wi-FiNC25
0
4
System LED:
Status Indication
Flashing Red
The camera starts booting up.
Solid Red
The camera has boot up, but is not connected to any network.
Flashing Green
The camera is in firmware upgrade procedure.
Solid Green
The camera is connected to a network or is transferring data.
2.3.2 Rear Panel
Figure 2-2 Rear Panel
WPS LED:
Status Indication
The camera starts booting up.
Flashing Green
The camera is connecting to a network by WPS function. This
process will last in the first 2 minutes.
The camera has boot up.
Off
The camera failed to be added to a network by WPS function.
Solid Green
The camera has been successfully added to a network by WPS
function. This process will last in the first 2 minutes.
ETHERNET Port
WPS LED
Power Jack
Heat Emission Holes
WPS/RESET
Button
