TP-Link RE605X User Manual

18
Chapter 4
TP-Link Cloud Service
4. 1. Register a TP-Link ID
When you log in after initial setup, the web page will ask whether you need TP-Link
Cloud service. You can also access the TP-Link Cloud settings as follows:
1. Visit http://tplinkrepeater.net, and log in with the password you set for the extender.
2. Go to Settings > TP-Link Cloud.
3. Click Register Now and follow the instructions to register a TP-Link ID.
4. After activating your TP-Link ID, come back to the TP-Link Cloud page to log in. The
TP-Link ID used to log in to the extender for the first time will be automatically bound
as an Admin.
Notes:
• To learn more about the Admin and User TP-Link ID, refer to Manage the User TP-Link IDs.
• Once you have registered a TP-Link ID on the web management page, you can only register another TP-Link ID via the
Tether APP. Please refer to Manage the Extender via the TP-Link Tether App to install the app and register a new one.
• If you want to unbind the admin TP-Link ID from your extender, please go to Settings > TP-Link Cloud, an click Unbind
in the Device Information section.
4. 2. Change Your TP-Link ID Information
Follow the steps below to change your email address and password of your TP-Link ID
as needed.
1. Visit http://tplinkrepeater.net, and log in with your TP-Link ID.
2. Go to Settings > TP-Link Cloud, and focus on the Account Information section.
• To change your email address:
1. Click
behind the Email.
2. Enter the password of your TP-Link ID, then a new email address. And click Save.

TP-Link RE605X Specifications

General

Type	Network repeater
Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Browser supported	Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Built-in power socket	No
Ethernet LAN data rates	1000 Mbit/s
Maximum transfer distance	- m
Ethernet LAN (RJ-45) ports	1
Maximum data transfer rate	1201 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
WLAN data transfer rates supported	574, 1200 Mbit/s
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	10 W
Antenna type	External
Product color	White
Antennas quantity	2
Country of origin	China
Quantity per pack	1 pc(s)
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Wi-Fi data rate (max)	1200 Mbit/s
Transmitting power (CE)	2.4 GHz ≤15dBm, 5 GHz ≤21dBm dBm
Package type	Box
Package depth	125 mm
Package width	202 mm
Package height	97 mm
Package weight	420 g
Sustainability certificates	CE, RoHS
Commodity Classification Automated Tracking System (CCATS)	85183095
Harmonized System (HS) code	85176990
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	79 mm
Width	74 mm
Height	124.8 mm
