Introduction
The TL-ANT2424MD, 2.4GHz 15dBi 2x2 MIMO Dish Antenna, can be used
with the outdoor wireless Base Station WBS210 to achieve a stable
long-distance point-to-point signal transmission.
The TL-ANT5830MD, 5GHz 19dBi 2x2 MIMO Dish Antenna, can be used
with the outdoor wireless Base Station WBS510 to achieve a stable
long-distance point-to-point signal transmission.
Specifications
Electrical Specifications TL-ANT2424MD TL-ANT5830MD
Frequency Range
Gain
VSWR
HPOL Beamwidth (3 dB)
VPOL Beamwidth (3 dB)
Elevation Beamwidth (3 dB)
F/B Ratio
Polarization
Impedance
Connector
2.3~2.7 GHz
24 dBi
1.8 Max
6°
6°
6°
32 dB Min
Horizontal & Vertical
50 Ω
RP-SMA
5.0 - 6.0 GHz
30 dBi
1.8 Max
6°
6°
6°
34 dB Min
Horizontal & Vertical
50 Ω
RP-SMA
Antenna Dimension
Weight
Rated Wind Velocity
Mounting
Φ 600 mm
6.0 Kg
241 Km/h
Pole Mount
Mechanical Specifications
