2
Package Contents
Heed all warnings:
Mount the antenna at a safe location, far away from power lines,
lamp posts, and other electrical cables.
Do not mount the antenna in the rain or thunderstorm.
Avoid using this product during an electrical storm. There may be a
remote risk of electric shock from lightning.
For your own safety, please seek a qualified service technician for
assistance.
Safety Notice
Antenna FeedDish Reector Antenna Mount Bracket
Installation Guide
Installation Guide
2x2 MIMO Dish Antenna
Model: TL-ANT2424MD & TL-ANT5830MD
M4 Bolts
(Qty. 4)
Pole-mount Clamps
(Qty. 2)
M10x150 Carriage Bolt Assemblies
(Qty. 4)
M10x35 Carriage Bolt Assemblies
(Qty. 3)
RF Cables
(Qty. 2)
Elevation Rod Protective Shroud
Below displays the package contents of the TL-ANT5830MD. The TL-ANT2424MD comes with
the Antenna Feed and RF Cables pre-attached.
