TL-R480T Enterprise Broadband Router User Giude
To add additional entries, repeat steps 1-4.
When finished, click the Return button to return to the Domain filtering page.
To Modify or delete an existing entry:
1. Find the desired entry in the table.
2. Click Modify or Delete as desired on the Edit column.
Click the Enable All button to enable all entries.
Click the Disable All button to disable all entries.
Click the Delete All button to delete all entries
Click the Next button to go to the next page and the Previous button to return to the
previous page.
For example: if you want to block the PCs on your LAN from accessing websites
www.xxyy.com.cn, www.aabbcc.com and websites with .net at the end on the Internet
while no limit for other websites. First, enable the Firewall and Domain
Filtering on the
Firewall page, then, specify the following Domain filtering list:
5.7.4 MAC Filtering
Like the IP Address Filtering page, the MAC Address Filtering page (shown in figure 5-27)
allows you to control access to the Internet by users on your local network based on their
MAC addresses.
Figure 5-27 MAC Address Filtering
Before setting up MAC Filtering entries, you must ensure that Enable Firewall and
Enable MAC Filtering have been selected on the Firewall page. To Add a MAC Address
- 33 -
