2.3.2 Rear View .3.2 Rear View
Power Jack
LAN Port
RESET Button
Base Plate
Power Jack: The power connector is where you connect the power adapter.
RESET: Press the button for more than 15 seconds, and the Camera will be restored to factory
defaults.
LAN Port: Through this port, you can connect the Camera to your computer or the other Ethernet
network devices.
Lock Ring: It is used to adjust the angle of the Camera.
Base Plate: It is used to support the Camera and can be fixed to a flat surface with the supplied
screws.
2.4 Mount the Camera
2.4.1 The Screw Size
