Standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a, IEEE
802.11e, IEEE 802.11i, IEEE 802.1X, IEEE 802.3X, IEEE 802.3,
IEEE 802.3u, IEEE 802.3ab
Protocols TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP
Ports
1 10/100M Auto-Negotiation Internet RJ45 port;
4 10/100M Auto-Negotiation Ethernet RJ45 ports supporting Auto
MDI/MDIX;
1 USB port supporting storage/FTP/Media/Print Server;
Cabling Type
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
LEDs
Power, System, Wireless 2.4GHz, Wireless 5GHz, Ethernet (1-4),
Internet, WPS, USB
Safety & Emissions FCC, CE
Wireless
Frequency Band* 2.4GHz, 5GHz
Radio Data Rate
11b: 1/2/5.5/11Mbps
11a/g: 6/9/12/18/24/36/48/54Mbps
11n: up to 300Mbps(2.4GHz), 300Mbps(5GHz)
Frequency Expansion DSSS (Direct Sequence Spread Spectrum)
Modulation
11n/g/a: QPSK,BPSK,16-QAM,64-QAM for OFDM
11b: CCK,DQPSK,DBPSK
Security WEP/WPA/WPA2/WPA2-PSK/WPA-PSK
Sensitivity @PER
1M: -98dBm@8%PER
11M: -92dBm@8%PER
6M: -93dBm@10%PER
54M: -75dBm@10%PER
65M/130M: -73dBm@10%PER
135M/270M: -66dBm@10%PER
Antenna Gain 2dBi@2.4-2.5GHz, 3dBi@4.9-5.825GHz
Temperature.
Operating: 0℃~40℃ (32℉~104℉)
Storage: -40℃~70℃ (-40℉~158℉)
Humidity
Operating: 10% - 90% RH, Non-condensing
Storage: 5% - 90% RH, Non-condensing
* Only 2.412GHz~2.462GHz is allowed to be used in USA, which means only channel 1~11 is available for
American users to choose.
