TL-WR542G 54Mbps Wireless Router User Guide
3
Figure 1-1 Front Panel sketch
Name Status Indication
Off Power off
PWR
On Power on
On The router is initializing or maybe has a system error.
Flashing The router is working properly
SYS
Off The router has a hardware error
Off There is no wireless device linked to the router
WLAN
Flashing The Wireless function is enabled
Off There is no device linked to the corresponding port
On
There is a device linked to the corresponding port but no
activity
WAN,1-4
Flashing There is an active device linked to the corresponding port
Table 1-1 The LEDs description
1.3.2 The Rear Panel
The following parts are located on the rear panel (View from left to right).
