61
Chapter 4
Configure the Router in Wireless Router Mode
PPPoEv6
• PPP Username/Password - Enter the User Name and Password provided by
your ISP. These fields are case-sensitive.
• Authentication Type – Choose one authentication type from AUTO-AUTH, PAP,
CHAP and MS-CHAP.
• Addressing Type - There are two types of assignation for IPv6 address:
SLAAC (Stateless address auto-configuration) and DHCPv6 (Dynamic Host
Configuration Protocol for IPv6) Server.
• MTU(Bytes) - The normal MTU (Maximum Transmission Unit) value for most
Ethernet networks is 1480 Bytes. For some ISPs, you may need to modify the
MTU. But this is rarely required, and should not be done unless you are sure it is
necessary for your ISP connection.
• Use IPv6 address specified by ISP - Input a static IPv6 address from the ISP.
• Set IPv6 DNS Server manually - Enter the IP address of the IPv6 DNS server
and secondary IPv6 DNS server.
Tunnel 6to4
