TP Toys Active Fun Explorer2 - Step 7: Height Configuration and Final Fixings; Low Height Assembly Completion; Full Height Assembly Continuation; Applying Final Securing Hardware

7
MT0336 712mm
x4
Fix using top
holes
Fix using
bottom holes
PM7074
25mm
x6
Low Height Assembly
Montage à faible hauteur
Montaggio per l’altezza più bassa
Montaje bajo
Halbhohe Montage
FA3839M
M6 x 12mm
x8
FA3839F
inc Spring Washer
M8 x 24mm
x8
For Low Height use
assembly is now
complete.
For Full Height
assembly
go to stage 9
Fix for Low
Height
assembly
only
10
TP Explorer Climbing Set with Platform & Den
