Assembly
Montage
Montaggio
Montaje
Montage
MT0332
x3
1
F
A2839M
M8 x 10mm
x1
F
A2839F
M10 x 13mm
x1
FA3839
Washer
x
1
F
A7151
Spring
Washer
x
1
6
TP Explorer Climbing Set with Platform & Den
TP843 Explorer Frame Set Inst 5012 -B 10 15.qxp_TP843 Explorer Frame Set Inst 5012-B 10 15 19/10/2015 11:37 Page 6
