16
TP Triple Round Wood Multiplay
Stage
14
70mm Coachscrew x2
FA8439
Drill 5mm
Pilot holes
Stage
13
70mm Coachscrew x2
FA8439
Bracket
Roundwood
Swing Leg x1
FB6051
Drill 5mm
Pilot holes
Triple Roundwood Extension Top bar - section x1
MW0227 2865mm
Legs ( Swing Arm) x2
MW0200 2700mm
ASSEMBLY
TIP
Ensure pre-drilled
holes in MW0227
are vertical.
IMPORTANT
ASSEMBLY TIP
30mm
2 holes
must face
downwards
TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 16 25/09/2017 10:42
