TP Triple Round Wood Multiplay
6 x 155mm Woodscrew x6
FA9784
M8 x25mm
Washer
FA8440
x12
M8
Nylon Insert Nut
FA5174
x8
70mm Coachscrew x18
FA8439
4.5 x 40mm Woodscrew x60
FA4517
5 x 60mm Woodscrew x2
FA9768
M8 x 120mm Bolt x4
FA9771
M8 Hook bolt x4
FA9774
5 x 80mm Woodscrew x16
FA4521
Pack - 5Pack - 4
Fixings - SP0076
Swing Seat
FC5220
x2
Stake
PR5069
x4
Glide Ride
Bracket
PR5070
x2
Glider Seat
PM0520
x2
Glider
Foot Rest
PM0519
x2
Glider Downtube Top MT0523 x2
Glider Seat Tubes MT0522 x2
Glider Downtube Bottom MT0521 x2
M8 x 25mm
Bolt
FA8381
x2
Spacer
Bush (Bracket)
PM1989
x4
40mm
Coach screw
FA8380
x4
35mm
40mm
FA2827 Bolt/washer/locknut Set x4
M6 x 40mm
35mm
40mm
FA2828 Bolt/washer/locknut Set x4
M6 x 35mm
35mm
40mm
FA2829 Male/female Bolt Set x2
M8 x 21mm
35mm
40mm
FA2830 Male/female Bolt Set x2
M8 x 73mm
Fixings - SP0078
FA6100
x2
PR9554
x1
PR8163
x1
Plastic Toggle
PM8387
x8
Slide
PM9752
x1
4 x 16mm
Woodscrew
x16
FA4527
FA2826 Bolt/locknut Set x2
M6 x 40mm
35mm
40mm
M8
Nylon Insert Nut
FA5174
x2
Bracket
Roundwood
90 Degrees x2
FB6052
Bracket
Roundwood
Swing Leg x1
FB6051
